Introduction
You’re lining up the perfect drift when the motor bogs down—battery’s done. For anglers, the “right battery size” is the difference between calling it early and fishing the afternoon bite. This guide shows you, step-by-step, how to size a lithium battery for a 12V trolling motor, what really affects runtime, and how Sentorise LiFePO₄ keeps you moving, consistently.
Part 1 — Sizing Math You Can Trust
Step 1: Confirm system voltage. Most trolling motors are 12V; larger rigs may use 24V or 36V (two or three 12V batteries in series).
Step 2: Find max amp draw. Check your motor manual (e.g., 30A / 40A / 50A at full throttle).
Step 3: Calculate capacity (Ah) for your target runtime. Formula: Required Ah ≈ (Amp draw × Hours) ÷ 0.9
Example: a 30A motor for 5 hours → 30 × 5 ÷ 0.9 ≈ 167Ah. Choose ~170Ah total (one larger pack or two packs.
Pro tip: If you rarely run WOT.
Part 2 — Quick Reference (12V Setups)
| Thrust (12V) | Typical Max Draw | Suggested Sentorise Battery | Est. Max Runtime at Full* |
| 30 lb | ≈ 30A | 12V 100Ah LiFePO₄ | ≈ 3.0 h |
| 45 lb | ≈ 40A | 12V 100–150Ah LiFePO₄ | ≈ 2.2–3.3 h |
| 55 lb | ≈ 50A | 12V 150–200Ah LiFePO₄ | ≈ 2.7–3.6 h |
-
Mixed speeds typically extend runtime beyond these full-throttle figures.
Part 3 — Voltage & Boat Size (When 24V/36V Makes Sense)
-
12V: kayaks/canoes and small boats under ~16 ft.
-
24V: 16–22 ft; better efficiency and torque for mid-size boats.
-
36V: >22 ft or frequent strong currents/wind.
Shaft length rule: from mount to waterline + ~20 in ensures the prop stays submerged in chop.
Part 4 — Factors That Quietly Kill Runtime
-
Boat weight & load: heavier hulls and extra gear increase amp draw.
-
Conditions: wind, current, weeds = more throttle = more amps.
-
Prop efficiency: a clean, appropriate-pitch prop saves watts.
-
Wiring & connections: undersized cable or loose lugs waste power as heat.
-
Temperature: cold water/air raises load; choose packs with low-temp protection.
Part 5 — Charger Pairing (Don’t Skip This)
Use a LiFePO₄-compatible charger. As a simple rule of thumb:
-
50Ah → 10A charger
-
100Ah → 20A charger
-
150Ah → 30–40A charger
-
200Ah → 40A charger
For series systems (24V/36V) use separate 12V chargers or a multi-bank charger to keep packs balanced.
Part 6 — Mistakes to Avoid
-
Undersizing capacity just to save money → stranded afternoons.
-
Ignoring fit & weight → poor balance and awkward installs.
-
Using a lead-acid charger on LiFePO₄ → risk to BMS and cycle life.
-
Thin cables / bad crimps → voltage drop, hot lugs, wasted runtime.
-
No buffer → deep cycling every trip shortens life; keep 10–20% in reserve.
Why Sentorise for Trolling Motors
-
Tough & lightweight: high energy density with compact footprints for tight compartments.
-
Smart BMS + protections: over/under-voltage, over-current, short-circuit; low-temperature charge protection.
-
Bluetooth monitoring: check SoC and status at a glance.
-
Long life: thousands of cycles for years of fishing.
-
Trust & support: 5-year warrantyhttps://eu.sentorise.com/products/12v-100ah-underfloor-battery-slimline-h190
Conclusion
Sizing is simple math—voltage, amp draw, hours—but runtime lives or dies by details like prop, wiring, and conditions. Choose the right capacity, pair the right charger, and your trolling motor becomes quietly reliable, all day.
Ready to fish longer with confidence?
Additional Resource (PDF)
-
File: Sentorise_TrollingMotorBattery_Checklist.pdf
-
What’s inside: voltage check, capacity formula, quick reference table, charger pairing, saltwater notes, and safety care.
Download：Sentorise_TrollingMotorBattery_Checklist.pdf
